GrindingHub
Apr. 1, 2022
(An exhibition focusing on grinding-related technologies such as grinders, grinding wheels, measuring instruments, and software)
| Interactive Date | May 17th (Tue) - 20th (Fri), 2022 |
|---|---|
| Venue | Messe Stuttgart / Germany |
| Access |
|
Exhibition Overview
Shibaura Machine Co.,Ltd will participate in the GrindingHub 2022 exhibition to be held in Stuttgart Messe, Germany from Tuesday,May 17, 2022 to Friday,May 20.
We will introduce the outline of a high precision machining center "UVM-450" with CE standard specifications for the European market , that incorporates the elements of nano-processing technology that we have accumulated over 40 years.
By replacing conventional machining methods, jig grinding machines and profile grinding machines to UVM-450, we can propose a solution that realizes nano-level accuracy pursuit and productivity improvement, so please visit our booth.
Contents
-
Introduction of UVM -450 CE standard specifications for high precision machining center (panel exhibition and presentation)
-
Direct milled for generating gearing sample (Carbide Material)
-
Fuel cell separator mold processing sample (Carbide)
-
VR goggles processed sample (Ra5 nm) by milling & shaping
-
Cosmetic case design model processed sample (Ra5 nm)
High precision machining center UVM-450D(H)（Panel exhibition）
| Main specifications | UVM-450D（H） | |
|---|---|---|
| Stroke |
X-axis （Horizontal movement of table） |
570mm |
|
Y-axis （Cross movement of spindle） |
525mm | |
|
Z-axis （Vertical movement of spindle） |
250mm | |
| Table | Machining area | 500mm × 500mm |
| Table loading capacity | 100kg | |
| Machine Size | Depth（X-axis direction） | 2260mm |
| Width（Y-axis direction） | 2130mm | |
| Height（Z-axis direction） | 2420mm | |
| Machine Mass | 4800kg | |
Booth image
Booth location
